Fluid Systems, Inc. has the capabilities to customize: 250, 500, 1000, 1500, 3000 bbl mud systems. Our Engineers, Designers and Rig Personnel have almost three(3) decades of experience in oil & gas industries.
Fluid Systems, Inc.'s Linear Power Shakers are simple, rugged and reliable. The high "G" force and quick screen panel change makes it top of the line quality.
FSI designed this high volume cascading systems with advance high "G" force to obtain optimum performance. Its six pre-tensioned panels can be installed or replaced independently in less than five minutes.
- High "G" Force
- up to 34 ft2screening area
- Quick Screen Change
- High Capacity
- up to 2000 GPM
- Low Noise
- Simple Design
- Small Footprint
- Max.Process Capacity of 40 tons/hr
- Interchangeable Drive
- Light Weight Screen Basket
- Exceptional Drying Capability
Fluid Systems' centrifugal pumps are designed to charge desanders, desilters, mud mixing operations, also supercharging and fresh water transfer. Our careful selection and installation provide a long lasting pump service.
Each hydrocyclone represents a product of advanced design.With interdependence of its inlet, vortex and apex orifices, the separation of fine, light and coarse particles is achieved with superior results.
Agitators' Horsepower
Available: 5, 7.5, 10, 15, 20, 25 and others
FSI's Mud Gun Nozzles are of
special high wear resistant polyurethane
Designed with a "big bowl" for the max. separation of solids/liquid in two or three phases. Our casing is a high quality carbon steel with easy access to the drum with cover subdivided in three parts. Bowl and screw are completely made of stainless steel.
- Availlable with:
- 6 inch high shear low pressure
- 4 inch high shear low pressure
- Liquid Capacity: 500-1500 gpm
- Gas Capacity: up to 17.5 MMscf/d
- Working Pressure:125psi
FSI's vacuum degasser degasses drilling fluids when it passes across internal baffles. It is made of high-quality steel with internal surfaces coated with industrial epoxy and fiberglass baffles to resist wear and corrosion.
FSI's "3D" Double Deck Drier can recover silts and ultra fine sands, provide solids in a consistently stackable and conveyable form and requires no expensive chemicals or polymers.
- Interchangeable Drive
- Lightweight Screen Basket
- Easy Screen Change
- Minimal Floor Space
- High Capacity
- Exceptional Drying Ability
- High Product Recovery
- Simple Operation
- Low noise under 80dB
- Quick Screen Panel Change
- low maintenance
- Balance linear motion
- small foot print
- High "G" Force
- Double Deck Design
- 33.7 sq.ft screening area
- Rugged and reliable
- No lubrication
FSI designed this unit to replace many competitors' shaker beds at a fraction of cost of a new machine and achieve optimum performance. Processing rates vary with slurry content, percent solids and viscosity.
Fluid Systems, Inc. is a worldwide provider of solids control , screening and process technology to the Oil & Gas, Industrial and Mining Industries. From its humble beginning as one of the first companies to introduce Linear Motion Shakers, it now offers complete product lines for your complete mud and process systems. We cater your needs on zero discharge systems, dredging systems, solids/liquid separation, filtration systems, micro tunneling, waste water processing, fine solids and sizing separation, agricultural systems, HDD Systems, industrial, construction and environmental concerns.
